RCF SUB 9016-AS

RCF SUB 9016-AS

RCF SUB 9016-AS

RCF SUB 9016-AS

RCF SUB 9016-AS

RCF SUB 9016-AS

Description

The SUB 9016-AS is a powerful 16-inch active subwoofer delivering a maximum sound pressure level of up to 137 dB and powered by a powerful 4000-watt Class-D amplifier. The SUB 9016-AS is specifically designed for the rigors of stage use: It features a tour-ready, weatherproof enclosure with a durable polyurea coating and a removable front wheel for easy transport. Precise control via networked RDNet management offers adjustable EQ, delay, cardioid configuration, and customized crossover presets for use with RCF loudspeakers. The innovative contactless configuration via RDTap enables seamless setup even without power to the subwoofer, ensuring perfect integration at all times. Despite its compact dimensions and low cabinet weight, the SUB 9016-AS achieves powerful and defined bass reproduction, accurately reproducing even subtle variations in the low-frequency range.

Features

137 dB maximum sound pressure level
4000-watt Class-D power amplifier
Contactless RDTap configuration
Includes rain cover for the connector panel
Control via RDNet
BMC, EQ, Delay, Cardioid configuration
ACE crossover presets for RCF speakers
16-inch RCF Precision woofer with long throw
Removable front roller board (sold separately)
PowerCON TRUE1 TOP power connection

Specifications

Frequency response: 30 Hz & divide; 200 Hz
Max SPL @ 1m: 137 dB

Transducer

Woofer: 1 x 16'', 4'' v.c

Input/Output Section

Input signal: bal/unbal
Input sockets: XLR, RDNet Ethercon
Output connections: XLR, RDNet Ethercon
Input sensitivity: -2 dBu/+4 dBu

Processor

Protection circuits: Thermal
Limiter: Soft Limiter
Control: MUTE, VOL, PRESETS, RDTAP
RDNet: Oneboard

Power section

Total power: 4000 W peak, 2000 W RMS
Cooling: Convection/Forced
Connections: Powercon TRUE1 TOP IN/OUT

Physical data

Housing material: Plywood
Hardware: 2xM20
Handles: 1 handle per side
Pole Mount/Cap: M20 thread
Grid: Steel
Color: Black

Size

Height: 533 mm / 20.98 inches
Width: 570 mm / 22.44 inches
Depth: 600 mm / 23.62 inches
Weight: 45 kg / 99.21 lbs

Category M-R:

RCF active subwoofers
Color:

black
Number of Woofers:

1
Performance According To Manufacturer:

4000W
Power Rms:

2000W
Speaker Equipment:

1x 16 inches
Housing Material:

Wood
Steering:

RDnet | Bass motion control | ACE | RDTap
Active/Passive:

active

RCF SUB 9016-AS

SKU: 200131378

GTIN: 8024530023423

I'm sorry, not available at present

Price on request
