LD Systems MAUI 11 G3 SUB

Name: LD Systems MAUI 11 G3 SUB
Brand: LD Systems
SKU: 200130438
Price: 676.50 EUR
Availability: InStock

Item No.: 200130438

676,50 €

incl. 19% VAT (Paket)

pieces

In stock

Delivery time: 3 - 5 Workdays (DE - int. shipments may differ)

Payment Benefit:
Save 3% via bank transfer / advanced payment
Your price at checkout: 656,21 €

Description
Technische Daten

Product Information

Number of Woofers:

2
Woofer in Inches:

8
Performance According To Manufacturer:

1460W
Power Rms:

730W
Operating Mode:

Class D
Housing Material:

plywood
Bluetooth:

Yes
Dsp:

Yes

Product Description

Punchier and more powerful bass with the additional LD MAUI11 G3 SUB subwoofer.

With the MAUI 11 G3 SUB subwoofer, you extend the cardioid characteristics of our professional column speaker series into the bass range.

What does that mean?

Position the SUB, facing rearward, next to your MAUI® 11 G3, activate the cardioid preset, and experience controlled low-end at the rear while maintaining the powerful bass response at the front. The low frequencies at the rear of the system are attenuated by -15 dB.

For additional bass, position the SUB facing the same direction as your MAUI® 11 G3 and deactivate the cardioid preset.

Setting up the SUB in combination with your MAUI® 11 G3 system is quick and easy. Thanks to automatic column detection, the SUB immediately switches to FOLLOWER mode as long as no column is plugged in. The protective cover and rolling base are also recommended to facilitate transport and keep the SUB free from touring damage for as long as possible. The MAUI® 11 G3 SUB features the same design as the MAUI® 11 G3 subwoofer and is the perfect complement to take control of your low end.

LD Systems MAUI 11 G3 CB

90,40 €

incl. 19% VAT (Paket)

Available

Payment Benefit:
Save 3% via bank transfer / advanced payment
Your price at checkout: 656,21 €

LD Systems MAUI 11 G3 SUB PC

49,70 €

incl. 19% VAT (Paket)

Available

Payment Benefit:
Save 3% via bank transfer / advanced payment
Your price at checkout: 656,21 €

Produktart	PA Subwoofer
Typ	Subwoofer
Farbe	Schwarz
Max. SPL (Peak)	125 dB
Frequenzgang (-10dB)	39 Hz - 200 Hz
Gewicht	20,5 kg
Merkmale	Bluetooth-Audio-Streaming
Merkmale	DSP basierte Signalverarbeitung
Merkmale	Exzellentes Abstrahlverhalten
Merkmale	Mono-/Stereo-Betrieb

Subwoofer

Größe Tieftöner	2 x 8 "
Größe Tieftöner	2 x 203 mm
Magnet Tieftöner	Ferrit
Marke Tieftöner	Custom Made
Schwingspule Tieftöner	2 "
Schwingspule Tieftöner (mm)	50,8 mm
Gehäusebauart	Bassreflex
Gehäusematerial	15 mm Multiplex
Gehäuseoberfläche	Polyurea
Abmessungen Subwoofer (B x H x T)	305 x 607 x 403 mm
Gewicht Subwoofer	20,5 kg

Verstärkermodul (im Subwoofer integriert)

Verstärker	Class D
Systemleistung (RMS)	730 W
Systemleistung (Peak)	1460 W
Schutzschaltungen	Kurzschluss
Schutzschaltungen	Multiband Limiter
Schutzschaltungen	Schutz vor Gleichstrom
Schutzschaltungen	Schutz vor Überhitzung
Kühlung	Konvektion
Bedienelemente	Bluetooth
Bedienelemente	Cardioid On/Off
Bedienelemente	Main Level
Bedienelemente	Power On/Off
Bedienelemente	Sub Level
Anzeigeelemente	Bluetooth
Anzeigeelemente	Cardioid On/Off
Anzeigeelemente	Follower Mode
Anzeigeelemente	Power
Anzeigeelemente	Protect (Schutzschaltung aktiv)
Anzeigeelemente	Signal
Anzeigeelemente	Subwoofer Mode
Netzanschluss	IEC (Stromkabel inklusive)
Betriebsspannung	100 V AC - 120 V AC / 50 - 60 Hz
Betriebsspannung	220 V AC - 240 V AC, 50 - 60 Hz
Sicherung	T 3,15AL / 250 V
Leistungsaufnahme	300 W
Umgebungstemperatur	0 - 40 °C
Relative Luftfeuchtigkeit	<80% (nicht kondensierend)
Anzahl Line-Eingänge	2
Anschlüsse Line-Eingänge	Combo XLR / TRS
Anzahl Line-Ausgänge	1 x Sub OUT
Anzahl Line-Ausgänge	2 x THRU
Anschlüsse Line-Ausgänge	XLR male
Anzahl Lautsprecherausgänge	1
Anschlüsse Lautsprecherausgänge	Custom Made Multipin
Bluetooth-Standard	A2DP
Bluetooth-Audio-Decoder	AAC
Bluetooth-Audio-Decoder	SBC
